Next-Generation Speech Synthesizer for the Amstrad CPC 464 by Michael Wessel

-

This Next-Generation Speech Synthesizer for the Amstrad CPC 464 by Michael Wessel started with a breadboard and now a PCB. For the moment, they are 4 videos of the interface card on Youtube :

It uses an Emic 2, the other components in the design are : Atmega 328 for implementing a parallel (CPC) to serial interface, to bride from the CPC to the Emic 2; a 74LS373 flip flop, 2 G16v8 PLD's for address decoding and generation of the chip select signal, and some other gates. The hardware extension is at address &F9E1. The speech synthesizer requires almost no driver, since the microcontroller and the Emic 2 are implementing an intelligent interface. The Basic program shown in the videos is implementing a simple protocol, but basically, to talk to the speech synthesizer, one only needs to write bytes to port address &F9E1 (e.g., using OUT in BASIC). Interestingly, the interface from the CPC's parallel data bus to the Atmel was tricky to implement.

It isnt compatible at the momeent with the other Amstrad CPC synthesizers : Dktronics and SSA-1. Emic 2 requires Start- (S) and End-Token (CR) - whereas Dktronics and SSA-1 simply send the allophones. Emic 2 works buffered, asynchronously, Dk'tronics and SSA-1 work synchronously. To make it compatible with SSA-1 and Dk'tronics, it would a) need to translate between allophone bytes and Emic 2 "equivalents", and b) figure out start- and end-token and shuffle them into the data stream (maybe based on a speech pause timing criterion). Not so obvious. Speech won't be synchronous, but maybe doable.?




Restoring and modding an Amstrad CPC 6128 by C-E with photos

-

After the reparation of an Amstrad Notepad NC200 by C-E, it's the turn of the reparation and modding of an Amstrad CPC 6128 (copy and paste of a CPCWiki message with the permission of C-E, thanks to him).

Last time I went to Spain I was digging in my old bedroom, that is basically a time capsule that takes you back to the 80s/90s, and I found my original CPC 6128 hidden in a closet along with the color monitor that came with it. There was also an old PC PSU I was using to power the computer, a 3.5" drive, a few home made cables... It seems that I put everything there when I was given a bunch of Pluses for free in 1997. After that, I was mainly using a 6128 Plus. The poor guy was pretty battered: very yellow keyboard that is probably not original (those keys look like coming from a Plus); a crappy ABBA switch hanging from a pair of cables; lots of scratches here and there...

However, despite its condition, this Amstrad is still very important for me. I spent my childhood with the machine, me and my friends played countless games on it, I used it to program a lot of crappy stuff and a few "games"... in summary, lots of great memories. So, when I came back to UK I brought the guy with me to restore and mod it :)

This is what I am planning to do:

  • New caps
  • Dual OS
  • Centronics ports
  • ABBA switch (a decent one)
  • Reset switch
  • 5VCPC
  • Floppy drive restoration

and, if possible, internal RAM expansion.

Externally nothing will change besides the little hole for the reset switch and the case modification required to fit the Centronics ports. It will look like a Schneider 6128.

façade avant de l'Amstrad CPC CPC 6128

façade avant de l'Amstrad CPC 6128 et switch

arrière de l'Amstrad CPC 6218

So... I finally had time to do something with my old 6128. It is still a work in progress but I thought that I could give you an update and show some pics :) . The first thing I did was just to remove the board from the case and clean it a bit. Here is how it looked before cleaning. It is a 6128 board version 2.

carte mère de l'Amstrad CPC 6128 après nettoyage

Then, I removed all the electrolytic caps, the 40015 and the solder that was filling the holes for the centronic ports. To remove the 40015 I simply cut the pins and then they were removed one by one. I was using the old good braid all the time. Here is the stripped board.

carte mère de l'Amstrad CPC 6128 sans les condensateurs et le 40015

Before going on, I think that it is worth saying that it is NOT necessary to remove all the electrolytic caps in a CPC 6128. The only one that can be problematic if you install the 5VCPC is the cap near the power socket. Bryce found that if it is not OK the computer will likely reset. I just decided to replace them with high grade new ones because I felt like doing it, nothing else :) . In any case, if you decide to change the electrolytics, pay attention to one that is near the AY, it is a 50V 1uF NON POLAR cap.

The next step was to prepare the socket for the dual OS. I followed this tutorial from Bryce that describes all the necessary steps in great detail. This is my modded socket :

socket pour la ROM DUAL OS de l'Amstrad CPC 6128

After this I recapped the board and soldered the socket in place :

condensateurs et puce 40015 réinstallés sur la carte mère de l'Amstrad CPC 6128

Finally I installed the new ports. I attached them to the board first using screws and nuts and then I soldered the leads. There are quite a few, but it is still a reasonably fast process.

ports centronics rajoutés sur la carte mère de l'Amstrad CPC 6128

ports centronics rajoutés sur la carte mère de l'Amstrad CPC 6128

ports centronics rajoutés sur la carte mère de l'Amstrad CPC 6128

And it seems that it works... :)

l'Amstrad CPC 6128 en état de bon fonctionnement



Three clones of the Dk'tronics mouse interface left, created by Bryce and made by Talrek

-

There are still three clones left of the mouse interface sold for 27,50 € (France) or 31,50 € (worldwide). They are made by Talkrek, it's a clone of the Dk'tronics mouse interface created by Bryce.



HxC, Gotek, and now the DDI3 USB Floppy Emulator for Amstrad CPC 464 by Zaxon

-

The problem with a disk drive emulator HxC or Gotek for an Amstrad CPC 464 is that you still need a DDI-1 interface which is a disk drive controler. It's not anymore a problem with the DDI3 USB Floppy Emulator for Amstrad CPC464 by Zaxon which integrates the DDI and the USB management.

For more informations about the DDI3 USB Floppy Emulator go on Indie Retro News.

The video is done by Novabug.



An Amstrad GX4000 console was tortured to create a PC Engine SD by Starforce Pi

-

Seen on Gameblog (french site), each time a PC Engine SD is created, a poor Amstrad GX4000 console must die !

If you love the japanese PC Enngine console it's not a problem, but for the Amstrad CPC generation, it's a crime !

Screenshots incoming soon.



CPC 128K, an Amstrad CPC 6128 clone by Zaxon with some upgrades included

-

Seen on the Amstrad.EU Facebook group, a clone of an Amstrad CPC 6128 created by Zaxon with the following features :

  • 128 Kb RAM
  • DDI-1 compatible floppy interface
  • PS/2 keyboard interface
  • RGB video out on minidin 8 (video cable included
  • CRTC is UM6845R
  • Two slots for extensions cards

Il fabrique et vends également son clone d'Amstrad CPC 6128.





FPGAmstrad on MiST-board revision r005.8.14.1 by Renaud Helias (hardware Amstrad CPC emulation)

-

New version of the Amstrad CPC core for MiST by Renaud Helias is available.

  • TV mode using VSYNC/HSYNC xor and Gerald VSYNC/HSYNC width formula
  • This version was realised with atari forum team, testing several experimental forks
  • It does output 15kHz original signal on SCART. Do use mist.ini scandoubler_disable=1 (see http://github.com/mist-devel/mist-board/wiki/DocIni)
  • sorry FDC work will be for a next time : my r005.8.15 candidate version does fail 80% of arnoldemu FDC testbench...



New batch of the Dk'tronics mouse interface clone created by Bryce and made by Talrek available

-

For 27,50 € (France) or 31,50 € (worldwide), you can order one clone of the Dk'tronics mouse interface created by Bryce and made there by Talrek. Be quick before they are all sold, limited number.

The video let you see this interface used with an Amstrad CPC+ and a compatible Logitech RX250 mouse with this interface. It should be found easily.



Restoring an Amstrad Notepad NC200 by CE with photos (and thanks to a lot of people)

-

With the permission of CE (without asci characters), here is the copy and paste of a message on CPCWiki about repairing an Amstrad NC200 with a lot of photos. Thanks CE.

I want also to thank all the writers and readers of the Amstrad forums I go (CPCwiki, CPCRUlez, Amstrad.ES, Amstrad.EU, etc...), Youtube users for their videos, those who write programs for our beloved Amstrad computers, or who make hardware for them. Without you all this site wouldnt exist (or would be really empty). Thank you all for making Amstrad computers still live more than 30 years after the CPC was created.

Below you can see the computer when I received it. It seems that in 1997 it was brought to some sort of technical service because the space bar was not working anymore. In there, they said that it was not possible to repair it and the NC200 went back to its owner. It was probably laying around since then, until they decided to get rid of it. I know that many of these machines were actually not used very often, but this is not the case. Whoever had it first worked with the laptop a lot: you can see marks here and there and a few shiny keys.

front of an Amstrad Notepad NC200  Amstrad Notepad NC200 open, screen and keyboard visible

The first thing I did was to power it on and check that, as the seller said, the keyboard was actually not working properly. The display was fine besides the backlight, that turned out to be extremely dim. There was also a decent layer of crap covering it.

The second thing was to disassemble the machine. It is quite easy. You have 5 screws on the bottom and a few clips on the keyboard region. Take the screws first and then lift the case a little bit in a careful way. The clips from the keyboard can be released introducing a little plastic sheet in the gap between the two shells and moving it around, or even with your fingers. In any case, be careful not to damage the case around the keyboard, this computer had been opened in the past in a very clumsy way and there was already a small crack that I had to repair with epoxy resin (more of this at the end). You can see four of the five screws to be removed in the next image. The last one is inside the battery compartment. They have different sizes, remember their original position.

back of an Amstrad Notepad NC200

Once you remove the upper part of the case you have to disconnect the cables that go to the screen. Be careful, the white one is short.

keyboard of an Amstrad Notepad NC200 with the screen removed

It is time to take out the floppy drive, the motherboard and the keyboard. There are a few screws holding everything in place.

keyboard of an Amstrad Notepad NC200 without the floppy drive

The external structure of the keyboard is similar to the one found in many other Amstrad. To open it you need to remove 3 screws and release a few clips.

removing crews to go at the Amstrad Notepad NC200 keyboard

In my case the membrane was extremely dirty. It seems that some liquid fell onto the keyboard in the past and entered between the two layers sticking them together. I used isopropanol to dissolve the crap and give it a good clean. Luckily, the solvent did not affect the fused plastic that joins the two layers, otherwise it would have been necessary to re-glue them. It seems obvious but when you see that two layers of a membrane are stuck by something that dried between them you should never try to separate them by pulling. There is very decent chance to damage the tracks.

Below is how it looks after the cleaning. Some of the silver is darker because there was some oxidation going on, but this does not affect conductivity or makes the tracks more prone to break. The oxide layer is extremely thin. In case of broken or corroded tracks it would have been necessary to reconstruct them with silver paint. This can happen if acid liquids, like orange juice, are spilled on the machine.

membrane of the Amstrad Notepad NC200 keyboard

Now onto the keyboard itself. There was nothing important here. The only thing that was out of place was the clip that makes the SPACE bar to go down uniformly when you press it. I put it back in place and cleaned the keyboard with lots of KH7 and water. Everything is made of plastic besides the metal clips, so no worries about oxidation. After cleaning you just need to manually dry the clips and let the rest dry by itself. If you do not dry them it is fine too, but I like to do it.

keyboard of an Amstrad Notepad NC200 without the space key

Time to reassemble the keyboard. We do not have nice springs, like in the CPC range, but rubber domes with the same function. I do not like this solution because it changes the keyboard feeling and the domes look a bit on the fragile side, but I must say that they are still in perfect condition. Maybe Amstrad engineers were not so wrong after all.

rubber domes of the Amstrad Notepad NC200 keyboard

The next thing was the backlight. The NC200 is reported to have a bright backlight that, in my case, was extremely dim. I asked Bryce about the backlight on his unit but, before he could check, I decided to replace the caps in the board and the light came back clear and strong. It seems that one or more of them went bad over time and this was giving the circuit a hard time. Replacing the caps is easy and their values completely common (sorry, I trashed the note where I wrote them). It should be a relatively simple task if you have some soldering skills but there is a very important thing to remember: some of them NEED to be low profile. Look at the picture below, it is the mainboard with the new caps. THE ONES MARKED WITH RED ARROWS NEED TO BE SHORT, otherwise you will not be able to re-install the floppy drive or close the case.

mainboard of the Amstrad Notepad NC200

Finally, onto the floppy drive. It is a very special model (Citizen V1DC-65B) or, at least, this is the first time I come across it. When I tried to format a floppy in the hope that it would work I found that it was not OK. Sometimes it was able to read something but most of the time you could hear the motor making noises and struggling with the old belt. Therefore, I opened it to see if it was possible to install a new one.

The first thing is to unscrew the upper shield to have access to the guts. It is not necessary to remove the frontal plastic bezel at all for this.

floppy drive of the Amstrad Notepad NC200

The second thing you need to do is to lift the head of the drive and remove the floppy support. It is very easy, just pull it back a little bit and it will come out. The springs that keep the floppy in place are also part of a mechanism that allow easy removal of the whole support. Funnily enough, the drive has a LED but you cannot see it when the machine is working because there is no hole in the bezel. It is very important not to forget to lift the head (not yours, the black plastic thing in the middle of the drive). Otherwise you could easily damage it and it is very delicate.

first inside of the Amstrad Notepad NC200 floppy drive

And here is the inner part of the drive once you remove the screws of the motor. The belt was in pretty bad condition and not elastic anymore.

second inside of the Amstrad Notepad NC200 floppy drive

The belt needs to be 2 mm wide, otherwise it will not fit into the grooves of the guide bushings. There is more tolerance with the thickness. The original is 2 mm wide and something like 0.5 mm thick, but the substitution belt is 2 mm wide and 2 mm thick. Regarding the diameter, something around 70 mm should work. You do not want it much smaller because then it would be necessary to overstretch the rubber and that would not be good. Luckily, although the new belt is thicker it does not touch anything in the board.

third inside of the Amstrad Notepad NC200 floppy drive and belt

To assemble the drive you need to follow the same steps but in reverse order. Remember to lift the head to put back the floppy support! Once it was ready I formatted a few discs, saved several files and loaded them back. Everything was fine.

screen of the Amstrad Notepad NC200

The next step was to detail the plastic case a little bit and reassemble the NC200. Then I did some more testing before closing the machine for real. Before you do this remember to align the slider that adjusts the contrast with the variable resistor on the board, otherwise you may have to open it again.

thest of the Amstrad Notepad NC200 keyboard

And here it is, happy and working! There was nothing extremely wrong with it, but quite a few little things.

main menu of the Amstrad Notepad NC200  tetris being played on Amstrad Notepad NC200

As I said at the beginning, there is something worth mentioning regarding the plastic used to make this computer. I found it not particularly robust when compared to a regular Amstrad CPC or Plus. My NC200 had a crack near the keyboard that I am sure appeared when somebody tried to open it in the past. There are also some small marks in the case because the same or other person introduced something in the gaps between the two shells, probably metallic, to separate them. I repaired the crack with epoxy and it is fine now but you really want to be careful when opening the laptop. What I did was to fill it with resin and add some extra epoxy around. It is all in the inner part of the shell and, therefore, not visible from the outside.

crack in the Amstrad Notepad NC200 keyboard

There is still a final tip: the NC200 needs 7.5V and 1A to run. There are many PSUs suitable for it but the polarity is reversed when compared to the CPC range. That is, outside you have the positive and inside the negative. This is written in the case of the machine but many people have burnt the internal fuse because of this. Keep it in mind and remember that if somebody sells on e-bay a not working unit this is possibly the case and most likely it can be repaired.




Hardware test of the Amstrad NC100 Notepad Computer by ChinnyVision

-

Another hardware test by ChinnyVision about the Amstrad NC100 Notepad Computer sold in 1992, an interesting portable computer, which existed also for the french and italian market as the Notepad NC150, and a later model the Notepad NC200 with a disk drive (1993).

The Amstrad Notepad NC100 has a Zilog Z80 processor like the Amstrad CPC and PCW, 64 Kb of RAM, a RS232C serial port, printer port, PCMCIA port to add a memory card (1 Mb maximum). The LCD screen has 8 rows of 80 characters (480 x 64 pixels). Used with 4 AA cell batteries, the NC100 can run for about 20 hours. The english manual of the Notepad NC100 is available for download.

Its features are :

  • Protext word processor (already on Amstrad CPC and Amstrad PCW)
  • spreadsheet (only on NC150 and NC200)
  • diary (word processing entries with a date)
  • address book
  • time manager (configurable alarm)
  • calculator
  • BBC BASIC interpreter
  • games (only on NC150 and NC200)

The Amstrad notepad NC100 can be used with the original interface/OS or with ZCN by Mark Russel wich is a native CP/M, or with Fuzix which is an unix (system 5) by Alan Cox.

You can emulate an Amstrad NC100 (and also NC150 and NC200) with nc100em (still by Mark Russel) for linux or ms-dos and a windows (port by Stefano Bodrato). The MESS emulator also supports the 3 Amstrad notepad NC. If you dont have the original NC100 ROM, you will need the ZCN.BIN file included in ZCN v1.3.

You will find more informations about the Amstrad Notepad NC on the excellent Tim's Amstrad NC users site where you will find programs for your NC100, see also the ZCN page.

Others youttube videos about Amstrad Notepad NC computers :
